Description
Looking for the best ST Link V2 Programmer Price in BD? The USB ST-Link V2 SWD & SWIM Programmer Module is a compact, cost-effective in-circuit programmer and debugger designed specifically for STM32 (ARM) and STM8 microcontrollers. At HTE Bangladesh, we provide reliable electronic components with fast delivery across the country, making it easy for engineers, students, and hobbyists to get started with embedded systems development.
Key Features & Benefits
- Dual Interface Support: Features SWD (Serial Wire Debug) for STM32 microcontrollers and SWIM (Single Wire Interface Module) for STM8 series.
- Dual Power Output: Built-in 3.3V and 5V power supply pins to power target microcontrollers directly during programming.
- Overcurrent Protection: Includes an internal 500mA self-recovery fuse to protect your PC’s USB port from short circuits or current surges.
- Plug & Play: Compact USB dongle form factor with clear pinout diagrams printed directly on the outer casing for quick reference.
- Status Indicators: Dual LED indicators (Red/Blue) to monitor power status and data transmission in real-time.
Close-up of the 4-pin SWD/SWIM header connection with jumper wires.
? Technical Specifications
| Specification | Details |
|---|---|
| PC Interface | USB 2.0 (Full Speed) |
| Operating Voltage | 5V (USB Powered) |
| Target Output Voltages | 3.3V DC & 5V DC |
| Supported Interfaces | SWD (4-pin), SWIM (4-pin) |
| Pin Header Pitch | 2.54 mm (Standard Dupont Cable compatible) |
| Protection | 500mA Self-Resetting Polyfuse |
| Material / Enclosure | Aluminum Alloy Shell |
? Additional Info & Package Contents
The USB ST-Link V2 SWD & SWIM Programmer Module comes securely packaged in an anti-static bag. Package contents include 1 × ST-Link V2 USB Programmer Module and 1 × 4-Pin Female-to-Female Jumper Wires.
? Application Section
The USB ST-Link V2 SWD & SWIM Programmer Module is widely used for debugging, flashing firmware, and developing applications on STM32 ARM Cortex-M based development boards and STM8 industrial microcontrollers. It is an essential tool for IoT projects, academic robotics, and professional embedded hardware design.
✅ Why Buy from HTE Bangladesh?
HTE Bangladesh is your trusted source for genuine microcontrollers, programmers, and sensors in Bangladesh. When you buy the ST-Link V2 programmer from us, you get authentic hardware, competitive pricing, and reliable customer support.
❓ Frequently Asked Questions (FAQ)
What is the ST Link V2 Programmer Price in BD?
The ST Link V2 Programmer Price in BD generally ranges from BDT 350 to BDT 600 depending on the build quality, casing, and inclusion of jumper wires at HTE Bangladesh.
Does the ST-Link V2 support both STM32 and STM8?
Yes, the USB ST-Link V2 supports both STM32 microcontrollers via the SWD interface and STM8 microcontrollers via the SWIM interface.
What operating voltage does the ST-Link V2 module provide to target boards?
The ST-Link V2 module provides selectable target output voltages of 3.3V DC and 5V DC directly through its built-in power supply pins.
