PIC16F73 Microcontroller: High-Performance 8-Bit MCU
Table of Contents
- Introduction
- Features of PIC16F73 Microcontroller
- Applications
- Technical Specifications
- Why Choose PIC16F73?
- External Resources
Introduction
The PIC16F73 Microcontroller: High-Performance 8-Bit MCU is an industry-leading microcontroller designed for optimal performance and versatility. With its advanced PIC® architecture and integrated features like ADC, PWM, and serial communication capabilities, the PIC16F73 is ideal for applications in automotive, industrial, and consumer electronics. Whether you’re developing a robust automation system or a power-efficient electronic device, the PIC16F73 offers reliability and efficiency.
Features of PIC16F73 Microcontroller
Key Highlights:
- High-Performance Execution: Operates at 200 nanoseconds per instruction.
- Advanced Analog-to-Digital Conversion: Includes 5 channels of 8-bit ADC for precise measurements.
- PWM Integration: Features 2 Capture/Compare/PWM functions for enhanced control.
- Flexible Communication Protocols: Supports SPI™, I²C™, and USART communication.
Additional Features:
- Power-on Reset (POR) and Power-up Timer (PWRT) for stable initialization.
- Watchdog Timer (WDT) for reliable system operation.
- Low-Power SLEEP Mode: Ideal for energy-efficient applications.
- In-Circuit Serial Programming (ICSP™) via two pins for easy programming.
- Wide Operating Voltage Range: Functions between 2.0V and 5.5V.
Applications
The PIC16F73 Microcontroller is versatile and fits a wide array of applications:
Automotive Applications
- Engine management systems
- Sensor-based monitoring and control
Industrial Applications
- ADC-based measurement systems
- Motor control using PWM
Consumer Electronics
- Home appliances with energy-efficient modes
- Battery-powered devices
Other Advanced Use Cases
- Robotics
- IoT devices requiring ADC and communication interfaces
Technical Specifications
Specification | Details |
---|---|
Program Memory Type | Flash |
Program Memory Size (KB) | 7 |
CPU Speed (MIPS) | 5 |
ADC Channels | 5 |
Max ADC Resolution (bits) | 8 |
Timers | 2 (8-bit) |
Pin Count | 28 |
Operating Voltage Range (V) | 2.0 – 5.5 |
Temperature Range (°C) | -40 to 125 |
Package Dimensions | 3 x 3 x 3 cm |
Shipment Weight | 0.005 kg |
Why Choose PIC16F73?
Ease of Use
The PIC16F73 is designed with simplicity in mind, utilizing only 35 single-word instructions, making it beginner-friendly yet powerful for advanced applications.
Compatibility
Fully compatible with other Microchip devices like PIC16C5X, PIC12CXXX, and PIC16C7X, ensuring seamless integration into existing systems.
Cost-Effectiveness
Offers exceptional performance and features at a competitive price point, making it an ideal choice for both developers and manufacturers.
Trusted Reliability
Backed by Microchip’s industry reputation for quality and innovation, the PIC16F73 is a dependable solution for mission-critical applications.
