Infrared Obstacle Avoidance Sensor Module

Description

Table of Contents:

1. Overview of the Infrared Obstacle Avoidance Sensor Module
2. Key Features of the Infrared Obstacle Avoidance Sensor Module
3. Applications in Robotics and Automation
4. How the Infrared Obstacle Avoidance Sensor Works
5. Why Choose Our Infrared Obstacle Avoidance Sensor Module?
6. Product Specifications
7. Installation and Setup Guide
8. Compatibility with Arduino and Raspberry Pi
9. FAQs

1. Overview of the Infrared Obstacle Avoidance Sensor Module

The Infrared Obstacle Avoidance Sensor Module is an essential component for robotics and automation projects that require accurate and efficient obstacle detection. Whether you’re working on a self-driving robot, an automated vehicle, or a home automation system, this module delivers reliable performance with a detection range of 2cm to 30cm. Its wide detection angle of 35 degrees, coupled with a simple TTL output signal, makes it easy to integrate into various systems.

2. Key Features of the Infrared Obstacle Avoidance Sensor Module

• Precise Detection Range: The sensor module detects obstacles from 2cm to 30cm, offering flexibility in various environments.
• Wide Detection Angle: With a 35-degree detection angle, this sensor covers a significant area, reducing the need for multiple sensors.
• Low Voltage Operation: It operates at a safe DC voltage of 3.3V to 5V, making it ideal for low-power devices.
• TTL Output Signal: Simple output that can be directly read by microcontrollers like Arduino, Raspberry Pi, and more.
• Compact and Lightweight: Designed for easy integration without adding significant bulk to your projects.

3. Applications in Robotics and Automation

The Infrared Obstacle Avoidance Sensor Module is widely used in the fields of robotics, industrial automation, and home automation systems. Here are some of the top applications:

• Robotics: Use it for collision detection in autonomous robots, drones, and rovers.
• Automated Guided Vehicles (AGV): Perfect for warehouse robots to prevent collisions with objects.
• Smart Home Devices: Add obstacle detection to your smart vacuum cleaner or other smart home appliances.
• Obstacle Detection in Vehicles: This sensor can be used for parking assistance and safety systems in small vehicles.

4. How the Infrared Obstacle Avoidance Sensor Works

This module works by emitting infrared light and then detecting the reflection from nearby objects. The built-in IR transmitter sends out a beam, and when it encounters an obstacle, the reflected light is received by the IR receiver. The module then processes the reflected signal and outputs a TTL signal, indicating whether an obstacle is present within the specified range.

---

5. Why Choose Our Infrared Obstacle Avoidance Sensor Module?

When it comes to obstacle detection, accuracy and reliability are key. Here’s why our Infrared Obstacle Avoidance Sensor Module stands out:

• High Accuracy: Delivers reliable detection even in challenging environments.
• Cost-Effective: Offers great value for the price, making it suitable for large-scale projects.
• Made for DIY Projects: Perfect for both hobbyists and professionals working with Arduino and Raspberry Pi.
• Durable Build: Made with high-quality materials to withstand regular use.

---

6. Product Specifications

Specification	Details
Detection Range	2cm to 30cm
Detection Angle	35 degrees
Operating Voltage	DC 3.3V to 5V
Output Signal	TTL Level
Made In	China
Weight	10g

7. Installation and Setup Guide

Setting up the Infrared Obstacle Avoidance Sensor Module is straightforward, especially with Arduino or Raspberry Pi. Here’s a brief setup guide:

1. Connect the Power: Supply the module with 3.3V or 5V power.
2. Wiring: Use the provided pins to connect the sensor to your microcontroller.
3. Programming: Write a simple script on Arduino IDE or Raspberry Pi to read the TTL signal.
4. Testing: Place objects at varying distances to test the obstacle detection capabilities.

8. Compatibility with Arduino and Raspberry Pi

The Infrared Obstacle Avoidance Sensor Module is highly compatible with various microcontrollers, including:

• Arduino: Easily integrate with Arduino boards like Uno, Mega, or Nano.
• Raspberry Pi: Use the GPIO pins on Raspberry Pi for seamless connectivity.

9. FAQs

Q1: How accurate is the sensor?
A: The sensor provides a detection range of 2cm to 30cm with high accuracy for most robotics and automation projects.

Q2: Can I use this sensor outdoors?
A: While it can be used outdoors, it’s recommended for indoor use, as direct sunlight may interfere with the infrared signal.

Q3: What microcontrollers are compatible with this sensor?
A: It works well with popular platforms such as Arduino, Raspberry Pi, and ESP8266.

Internal Links:

• Explore more sensors
• Arduino-compatible modules

External Links:

• Arduino Official Guide
• Robotics Integration Guide

Conclusion

The Infrared Obstacle Avoidance Sensor Module is a must-have component for any robotics or automation project. With its reliable detection range, easy integration, and compatibility with popular microcontrollers like Arduino and Raspberry Pi, it’s the perfect choice for both hobbyists and professionals. Whether you’re building an autonomous robot or designing a smart home system, this sensor module will provide the accuracy and performance you need.
