Introduction to 3 Position DIP Switch 2.54mm Pitch
-
Key Features of 3 Position DIP Switch
-
Technical Specifications
-
Benefits of Using 3 Position DIP Switch
-
Common Applications
-
Why Buy from HTEBD?
-
Frequently Asked Questions (FAQ)
-
Conclusion
1. Introduction to 3 Position DIP Switch 2.54mm Pitch
The 3 Position DIP Switch 2.54mm Pitch is a compact, reliable, and widely used electronic component. It allows easy control and configuration of devices on PCBs (Printed Circuit Boards) and breadboards. With its three individual positions, this DIP switch provides binary-coded switching which is commonly used in electronics, communication systems, and industrial projects.
At HTEBD, you can find high-quality 3 Position DIP Switches that are ideal for students, engineers, and DIY electronics hobbyists in Bangladesh.
2. Key Features of 3 Position DIP Switch
Some of the most important features include:
-
Three switch positions for multiple configurations.
-
2.54mm standard pin pitch suitable for PCB and breadboard use.
-
Horizontal, Piano Type, Slide mechanism for easy switching.
-
Compact and lightweight design.
-
RoHS compliant – safe and eco-friendly.
-
Durable and long-lasting performance.
3. Technical Specifications
| Specification | Details |
|---|---|
| Product Name | 3 Position DIP Switch 2.54mm Pitch |
| Type | Horizontal / Slide / Piano Type |
| Material | Plastic, Metal |
| Pin Pitch | 2.54 mm |
| Position Number | 3 |
| Switching Rating | 100mA DC 50V / 25mA DC 24V |
| Contact Resistance | 50mΩ (Initial), 100mΩ (Typical) |
| Color | Red / Blue |
| Compliance | RoHS Certified |
4. Benefits of Using 3 Position DIP Switch
-
Easy Integration – Perfect for PCBs, breadboards, and project circuits.
-
Reliable Performance – Ensures long-term durability in various projects.
-
Compact Size – Saves space on boards without compromising functionality.
-
Versatility – Used in household electronics, industrial systems, and DIY projects.
-
User-Friendly – Simple ON/OFF toggle with clear markings.
5. Common Applications
The 3 Position DIP Switch 2.54mm Pitch is widely used in:
-
Consumer Electronics – Televisions, washing machines, and audio systems.
-
Telecommunication Systems – For device configuration and control.
-
Industrial Machines – Textile, printing, and mining equipment.
-
Musical Instruments – Digital pianos, keyboards, and amplifiers.
-
Educational Projects – Ideal for students and engineers on breadboards.
6. Why Buy from HTEBD?
When you choose HTEBD, you get:
-
✅ Original & high-quality electronic components.
-
✅ Affordable pricing in Bangladesh.
-
✅ Quick delivery nationwide.
-
✅ Trusted by students, hobbyists, and professionals.
-
✅ Customer support via Facebook Page.
7. Frequently Asked Questions (FAQ)
Q1: What is the pitch size of this DIP switch?
👉 The pitch size is 2.54mm, which fits perfectly into breadboards and PCBs.
Q2: How many switch positions does it have?
👉 It has 3 independent positions, each working as an ON/OFF toggle.
Q3: Can it be used in household appliances?
👉 Yes, this switch is widely used in telecoms, household electronics, and industrial projects.
Q4: Is it RoHS compliant?
👉 Yes, all 3 Position DIP Switches from HTEBD are RoHS compliant.
8. Conclusion
If you are working on electronics projects, PCBs, or industrial circuits, the 3 Position DIP Switch 2.54mm Pitch is a must-have component. Its compact design, reliable performance, and ease of use make it perfect for professionals, students, and DIY enthusiasts.
👉 Order now from HTEBD and get your 3 Position DIP Switch 2.54mm Pitch delivered anywhere in Bangladesh!
