Description
Looking for a reliable bio-potential measurement tool? The ADS1292R ECG Module is an exceptional 2-channel, 24-bit analog-to-digital converter designed specifically for electrocardiogram (ECG) and respiratory impedance measurements. Whether you are a biomedical engineering student working on a capstone project or a professional developing a portable medical device, this module delivers clinical-grade precision. At HTE Bangladesh, we make it easy to get genuine components with reliable delivery right to your doorstep. Apnader biomedical projects er jonno eeta ekti obosshoi dorkari sensor!
Features & Benefits
- Integrates a 2-channel, 24-bit delta-sigma ADC with built-in programmable gain amplifiers (PGA).
- Supports simultaneous ECG and respiratory impedance measurements for comprehensive health monitoring.
- Low power consumption, making it ideal for battery-operated wearable medical devices.
- Built-in pacing detection and lead-off detection capabilities for enhanced safety and accuracy.
- Compatible with popular microcontrollers like Arduino, STM32, and ESP32 via SPI interface.
Technical Specifications
| Specification | Details |
|---|---|
| Model | ADS1292R 2-Channel ECG and Respiratory Module |
| ADC Resolution | 24-Bit Delta-Sigma ADC |
| Channels | 2 Differential Channels |
| Operating Voltage | 2.7V to 3.5V (typically 3V) |
| Communication Interface | SPI-compatible |
| Sampling Rate | Up to 8 kSPS |
| Dimensions | Approx. 30mm x 25mm |
Additional Information
- Weight (Packaged): 50g
- Dimensions (Packaged): 10cm x 8cm x 3cm
- Package Includes: 1 x ADS1292R ECG and Respiratory Impedance Module, 1 x Lead-off Cable set (as applicable).
Applications
The ADS1292R ECG Module is widely used in patient monitoring systems, portable ECG devices, fitness heart-rate monitors, and biomedical research laboratories. Compared to basic analog pulse sensors, the ADS1292R provides true medical-grade digital conversion with built-in lead-off detection and respiratory measurement capabilities, making it the superior choice for advanced health diagnostics.
Call to Action
Ready to build your next biomedical device? Order the ADS1292R ECG Module today from HTE Bangladesh at the best price in Bangladesh! Ekhoni order kore apnar lab ba project-ti ke aro unnoto korun.
Frequently Asked Questions
Q: What is the primary function of the ADS1292R ECG Module?
A: The ADS1292R ECG Module is a 2-channel, 24-bit analog-to-digital converter specifically designed to measure electrocardiogram (ECG) signals and respiratory impedance simultaneously for biomedical and health monitoring applications.
Q: What microcontroller platforms are compatible with this module?
A: The module communicates via an SPI interface, making it fully compatible with popular microcontroller platforms such as Arduino, ESP32, STM32, and Raspberry Pi Pico.
Q: What is the operating voltage of the ADS1292R module?
A: The ADS1292R module operates at a voltage range of 2.7V to 3.5V, with 3V being the standard operating voltage typically supplied by development boards or regulated power sources.
