Description
High-Speed 74HC04 Hex Inverter (6 NOT Gate) IC
The 74HC04 Hex Inverter (6 NOT Gate) IC is an essential component for designing high-speed digital electronics. Featuring four independent 2-input OR gates, it operates on a wide voltage range of 2.0V to 6.0V. Whether you are an engineering student, a researcher, or a professional hobbyist, this IC ensures fast and reliable logic operations. At HTE Bangladesh, we provide highly authentic components at the best 74HC04 price in Bangladesh. আপনার ডিজিটাল লজিক সার্কিট এবং প্রজেক্ট তৈরি করার জন্য এটি একটি চমৎকার এবং সাশ্রয়ী সমাধান।
✨ Key Features & Benefits
- Wide Voltage Range: Operates efficiently between 2.0V and 6.0V.
- Low Power Consumption: CMOS logic technology makes it ideal for battery-powered circuits.
- Standard DIP-14 Package: Easy to mount on standard breadboards or PCBs, making prototyping seamless.
- High Noise Immunity: Ensures a stable and predictable output across noisy environments.
🔥 Specification Table
| Logic Type | Hex Inverter / NOT Gate |
| Number of Gates | 6 |
| Number of Inputs (Per Gate) | 1 |
| Operating Voltage (Vcc) | 2.0V to 6.0V |
| High-Level Output Current | -5.2 mA |
| Low-Level Output Current | 5.2 mA |
| Propagation Delay | ~8ns (at 5V) |
| Package / Case | DIP-14 (Through Hole) |
📦 Additional Information
- Dimensions: Approx. 19.3 x 6.35 x 7.1 mm
- Weight: ~1.0 gram
- Package Includes: 1 x 74HC04 Hex Inverter (6 NOT Gate)
🎯 Applications
- Boolean logic implementation in complex digital systems.
- Memory address decoding for microprocessors and microcontrollers.
- Industrial control systems, safety interlocks, and alarm triggers.
- University electronics lab experiments and Arduino/Raspberry Pi DIY projects.
✅ Why Buy From HTE Bangladesh?
We ensure premium quality electronic components. এই 2-Input OR Gate IC টি দ্রুততম সময়ে আপনার ঠিকানায় পেতে আজই অর্ডার করুন। Enjoy fast delivery, top-notch customer support, and secure payment options nationwide.
❓ Frequently Asked Questions (FAQ)
1. What is the operating voltage of 74HC04?
It supports a wide operating voltage from 2.0V to 6.0V, making it highly versatile for both 3.3V and 5V digital systems.
2. Is this IC compatible with a standard breadboard?
Yes, it comes in a through-hole DIP-14 pacpackage, fits perfectly on any standard 0.1-inch pitch breadboard.
3. Can I use it with an Arduino?
Absolutely! It works seamlessly with Arduino, NodeMCU, and Raspberry Pi for performing external hardware logic operations without consuming processing power.
