38kHz IR Receiver Module

৳ 15.00

Discover the 38kHz IR Receiver Module, a versatile and efficient infrared receiver compatible with various remote control codes.

Description

Table of Contents

  1. Introduction to the 38kHz IR Receiver Module
  2. Key Features
    • Integrated Photodetector and Preamplifier
    • Internal PCM Frequency Filter
    • Enhanced Anti-Interference Ability
  3. Specifications
  4. Applications
  5. How to Use the 38kHz IR Receiver Module
  6. Conclusion

1. Introduction to the 38kHz IR Receiver Module

The 38kHz IR Receiver Module is a critical component for any electronics enthusiast or professional working on infrared remote control systems. This module integrates a photodetector and a preamplifier in one compact package, making it a versatile choice for a wide range of applications. Its design includes an internal filter for pulse-code modulation (PCM) frequency, ensuring excellent performance even in challenging environments.

2. Key Features

Integrated Photodetector and Preamplifier

One of the standout features of the 38kHz IR Receiver Module is its integrated design, which combines a photodetector and a preamplifier. This combination allows for improved signal processing, enhancing the overall reliability and efficiency of infrared communication.

Internal PCM Frequency Filter

The internal PCM frequency filter ensures that the module effectively filters out noise and interference, allowing only the intended signals to pass through. This feature significantly improves the performance of infrared communication, making it suitable for high-quality applications.

Enhanced Anti-Interference Ability

With its inner shield design, the 38kHz IR Receiver Module boasts excellent anti-interference capabilities. This design minimizes the effects of ambient light and electrical disturbances, ensuring that your infrared communications remain clear and uninterrupted.

3. Specifications

  • Operating Voltage: 3.0V to 5.0V
  • Power Consumption: Low power, making it ideal for battery-operated devices
  • Compatibility: TTL and CMOS compatible
  • Transmission Codes Supported: NEC code, RC5 code
  • Frequency Response: 38kHz
  • Dimensions: Compact design for easy integration

4. Applications

The 38kHz IR Receiver Module is suitable for a wide range of applications, including:

  • Infrared Remote Control Systems: Ideal for controlling TVs, air conditioners, and other home appliances.
  • Robotics Projects: Perfect for remote-controlled robots, enhancing their functionality.
  • Home Automation: Used in smart home devices for seamless communication.

5. How to Use the 38kHz IR Receiver Module

Using the 38kHz IR Receiver Module in your projects is straightforward. Here’s a quick guide:

  1. Connect the Module: Connect the VCC pin to the power supply (3.0V to 5.0V), GND to ground, and the output pin to your microcontroller (like Arduino).
  2. Upload Code: Use libraries such as IRremote for Arduino to handle the incoming signals.
  3. Testing: Point your infrared remote control at the module and press buttons to test its functionality.

6. Conclusion

The 38kHz IR Receiver Module is an essential component for anyone interested in developing infrared-based applications. With its integrated design, low power consumption, and compatibility with various remote control codes, it provides an efficient solution for both hobbyists and professionals alike.
